G1771 pH7 Eye/Face Wash Wall Mounted – No Bowl
G1771 pH7 Eye/Face Wash Wall Mounted – No Bowl
$$ PRICE ON REQUEST – CONTACT HERE
Eye/face wash for wall mounting without bowl.
- Application: Eye/face wash for wall mounting. Two large FS-Plus™ spray-type outlet heads deliver a flood of water for rinsing eyes and face. Unit is provided without a bowl or drains for wastewater. Note: Floor drain should be provided underneath the unit to prevent the accumulation of water on the floor.
- Spray Head Assembly: Two FS-Plus™ spray heads. Each head has a “flip top” dust cover, internal flow control and filter to remove impurities from the water flow.
- Valve: 1/2” IPS chrome plated brass stay-open ball valve. The valve is US-made with chrome-plated brass ball and PTFE seals.
- Mounting: Heavy-duty cast aluminium wall bracket with corrosion-resistant powder-coated finish.
- Construction: Polished chrome-plated brass.
- Supply: 1/2” NPT female inlet.
- Sign: ANSI-compliant identification sign.
- Quality Assurance: Unit is completely assembled and water tested prior to shipment.
DOWNLOADS
- AS4775-2007 Compliance Checklist
- Catalogue Page
- Parts List
- Corrosive Guide
- Guardian Compliance Certificate
